In StockLifting Column

Fairino FR20 Palletizer, 20 kg, Fixed or Lifting Column

FAIRINO

$44,000.00

Fairino FR20 is a 20 kg payload palletizing station for automated stacking on standard 1200 mm pallets. Choose fixed-height (1100 mm) or lifting column (1140-1670 mm adjustable). Both run on 110V or 220V AC, stack to 1800 mm, and feature drag-and-drop programming, touch panel control, and Modbus/TCP/IP connectivity.

Fairino FR20 Palletizer, 20 kg, Fixed or Lifting Column

Fairino FR20 is a robotic palletizer machine engineered for automated palletizing solutions in packaging, logistics, and machine tending environments.

Key Specifications:

Payload Capacity: 20 kg
Stacking Height: up to 1800 mm
Repeatability: 0.1 mm
Pallet Sizes Supported: 1200×1000 mm, 1200×800 mm

Configuration Options:

Fixed-height model: 1100 mm
Lifting column model: adjustable from 1140 to 1670 mm

Mounting and Mobility: The mobile lifting column version weighs 280 kg and is designed for easy repositioning by a single operator, while the fixed option suits permanent installation.

Control and Integration Features:

Power Supply: AC 110V or 220V
Communication Interfaces: Modbus, TCP/IP, digital I/O standard; Profinet, EtherCAT, and Ethernet/IP optional
Programming: Integrated touch panel, WebApp, and mobile device support. Graphical drag-and-drop interface and SDKs for C#, C++, and Python.

Advantages over Fixed-Height Palletizers:

Lifting column option enables adaptable stacking heights for various product dimensions and warehouse layouts
Quick deployment for dynamic multi-level palletizing projects
Single-operator mobility simplifies workflow adjustments

Applications:

Palletizing station for packaging and logistics
Machine tending and pick-and-place operations
Multi-size product stacking for variable production lines

Frequently Asked Questions:

What pallet sizes fit? Standard 1200×1000 mm and 1200×800 mm pallets are fully supported.
What power supply is needed? Both 110V and 220V AC power sources are compatible with Fairino FR20.
Can it be moved? The mobile version with lifting column weighs 280 kg and can be repositioned by a single operator.

Explore More Palletizing Solutions:

Browse Palletizing Solutions for related robotic palletizer models and application stations.

Max Payload20 kg

Repeatability: 0.1 mm
Max. stacking height: 1 / 800 mm
Weight: 280 kg
Payload: 20 kg
Reach: 1140 to 1670 mm
Mounting Interface: Fixed or Lifting Column
Power Supply: 110V or 220V AC
Pallet Size: 1200×1000 mm, 1200×800 mm
Max Stacking Height: 1800 mm
Control Options: Integrated touch panel, WebApp, Mobile devices
Programming: Graphical drag-and-drop, C#, C++, Python
Communication: Modbus, TCP/IP, Digital I/O, Profinet, EtherCAT, Ethernet/IP

Runs on AC 110V or 220V, no special power infrastructure needed
Handles standard 1200×1000 mm and 1200×800 mm pallets
One person moves the lifting column unit, 280 kg total weight
Control via touch panel, WebApp, or mobile devices for flexible operation
Drag-and-drop graphical programming plus C#/C++/Python SDKs cut setup time
Modbus, TCP/IP, digital I/Os standard, Profinet/EtherCAT/Ethernet/IP optional
Palletizing software built in, no coding required for configuration
Stacks up to 1800 mm high with lifting column, expands workflow options
Repeats picks to 0.1 mm accuracy, ensures consistent stack quality

: The Fairino FR20 is a robotic palletizer that automatically stacks products onto standard pallets in packaging, logistics, and machine tending environments. It handles 1200×1000 mm and 1200×800 mm pallets and can stack up to 1800 mm high with the lifting column option.
: The Fairino FR20 has a 20 kg payload capacity and repeats picks to 0.1 mm accuracy for consistent stack quality.
: Yes, the lifting column model weighs 280 kg total and can be repositioned by a single operator, making it suitable for flexible workflow adjustments. The fixed-height model is designed for permanent installation.
: The Fairino FR20 runs on AC 110V or 220V, so no special power infrastructure is required.
: The FR20 features built-in palletizing software with no coding required for configuration, plus drag-and-drop graphical programming and SDKs for C#, C++, and Python. You can control it via touch panel, WebApp, or mobile devices.
: Modbus, TCP/IP, and digital I/Os are standard, with Profinet, EtherCAT, and Ethernet/IP available as optional add-ons.

Automated palletizing vs. manual stacking or fixed-height systems:

The FR20 bridges flexible production needs. Choose it when you need to adjust stacking heights across different product types, move the system between lines, or require consistent 0.1 mm accuracy without manual labor. The lifting column model suits dynamic warehouses; the fixed model suits permanent stations.

For products up to 20 kg on standard 1200×1000 or 1200×800 mm pallets, the FR20 stacks reliably to 1800 mm high, adapting to variable product dimensions.
On tight production floors, one operator repositions the 280 kg lifting column unit between cells, avoiding costly installation for each new layout.
In multi-SKU lines where stack heights shift frequently, the adjustable lifting column (1140 to 1670 mm) cuts changeover time versus fixed-height machines.
Where touch-panel or mobile control is preferred, built-in palletizing software and drag-and-drop graphical programming skip coding overhead and accelerate deployment.
On sites with only 110V or 220V standard AC power, the FR20 runs without special infrastructure upgrades.
