What is a parallel gripper?

A parallel gripper is an end effector with two fingers that move toward and away from each other in parallel motions to clamp workpieces. The Zimmer Group GEP2010IO-05-B is a compact 2-finger parallel gripper designed for small parts automation, pick and place, and assembly handling.

What is the gripping force on the GEP2010IO-05-B?

The Zimmer Group GEP2010IO-05-B delivers 200N of gripping force per jaw to secure small parts reliably. This force is maintained across a 10mm stroke per jaw.

Does the GEP2010IO-05-B hold parts when power is lost?

Yes, the GEP2010IO-05-B has a self-locking mechanism that keeps workpieces securely grasped during power loss without requiring continued energy supply. This design ensures safe holding even in unexpected power interruptions.

How do I integrate the GEP2010IO-05-B with my robot controller?

The GEP2010IO-05-B integrates via digital I/O control, which streamlines connection with robotic controllers and automation platforms. Mounting is flexible on multiple sides with removable centering sleeves for fast setup.

What temperature can the GEP2010IO-05-B operate in?

The GEP2010IO-05-B operates reliably in ambient temperatures up to 60°C, making it suitable for high-cycle applications in warm industrial environments.

How accurate is the positioning on the GEP2010IO-05-B?

The GEP2010IO-05-B achieves repeatability of 0.02mm, providing consistent and precise positioning for pick and place accuracy in automated applications.

Zimmer Group GEP2010IO-05-B Electric Gripper, 10mm stroke, 200N

Not sure it fits your cell? Book 20 minutes with an engineer who has specified this part before.

Book a call

Ordered the wrong size or interface? Here is exactly how sending it back works.

In Stock800N Grip

Zimmer Group GEP2010IO-05-B Electric Gripper, 10mm stroke, 200N

Name: Zimmer Group GEP2010IO-05-B Electric Gripper, 10mm stroke, 200N
Brand: Zimmer Group
SKU: 3042
Price: 1895 USD
Availability: InStock

ZIMMER GROUP GmbH

$1,895.00

Zimmer Group GEP2010IO-05-B electric gripper with 10mm stroke per jaw, 200N gripping force, and 0.02mm repeatability. Compact 0.3kg parallel gripper with self-locking retention and digital I/O control for small-part automation, assembly, and pick-and-place operations. Rated to 60°C.

Zimmer Group GEP2010IO-05-B is a compact 2-finger electric parallel gripper engineered for precise small parts automation, pick and place, and assembly handling in industrial environments.

Key Features:

Gripping force: 200N for secure small parts handling
Stroke: 10mm per jaw
Unit weight: 0.3kg
Repeatability: 0.02mm for consistent positioning
Mounting interface: Multiple sides with removable centering sleeves

Performance and Integration:

Digital I/O control streamlines integration with robotic controllers and automation platforms
Self-locking design keeps workpieces securely grasped during power loss without continued energy supply
Ambient temperature rating: up to 60°C, suitable for limited-access and high-reliability cycles

Application and Use Cases:

Optimized for compact electric gripper small parts automation
Ideal as a pick and place gripper for automated machine tending
Recommended where a parallel gripper offers higher cycle speed and reliability versus pneumatic alternatives
Related solutions available in electric grippers and end effectors and tooling categories

Zimmer Group GEP2010IO-05-B is the preferred self-locking gripper automation tool when cycle reliability, secure holding, and simple integration are critical.

Weight0.3 kg

Weight0.3kg

Stroke per jaw10 mm

Max Gripping force: 200 N
Propulsion Method: Electric
Max. ambient temperature: 60 ℃
Repeatability: 0.02 mm
Payload: 200N
Stroke: 10mm
Control: Digital I/O
Self-Locking: Yes
Operating temperature: up to 60°C

Handles small parts precisely with zero maintenance, compact 2-jaw design
Holds workpieces securely during power loss thanks to self-locking mechanism
Integrates instantly with digital I/O control into existing automation systems
Mounts flexibly on multiple sides with removable centering sleeves for fast setup
Grips reliably at 200N force across 10mm stroke per jaw
Positions repeatably to 0.02mm for consistent pick and place accuracy
Operates reliably up to 60°C ambient temperature in high-cycle applications

: A parallel gripper is an end effector with two fingers that move toward and away from each other in parallel motions to clamp workpieces. The Zimmer Group GEP2010IO-05-B is a compact 2-finger parallel gripper designed for small parts automation, pick and place, and assembly handling.
: The Zimmer Group GEP2010IO-05-B delivers 200N of gripping force per jaw to secure small parts reliably. This force is maintained across a 10mm stroke per jaw.
: Yes, the GEP2010IO-05-B has a self-locking mechanism that keeps workpieces securely grasped during power loss without requiring continued energy supply. This design ensures safe holding even in unexpected power interruptions.
: The GEP2010IO-05-B integrates via digital I/O control, which streamlines connection with robotic controllers and automation platforms. Mounting is flexible on multiple sides with removable centering sleeves for fast setup.
: The GEP2010IO-05-B operates reliably in ambient temperatures up to 60°C, making it suitable for high-cycle applications in warm industrial environments.
: The GEP2010IO-05-B achieves repeatability of 0.02mm, providing consistent and precise positioning for pick and place accuracy in automated applications.

Electric gripper versus pneumatic for small parts automation:

The Zimmer GEP2010IO-05-B is a compact electric parallel gripper built for high-cycle precision work where pneumatic alternatives require ongoing air supply and offer less repeatability. Choose this gripper when cycle speed, part security during power loss, and zero maintenance outweigh the need for very high force or very long strokes.

For parts under 5 kg in tight robotic cells, the 0.3 kg weight and compact 2-jaw design free payload for heavier end-of-arm tools or sensors.
Where repeatability under 0.05 mm matters, the 0.02 mm positioning accuracy beats standard pneumatic grippers for consistent pick and place on small assemblies.
During unplanned power interruptions or emergency stops, the self-locking mechanism holds parts securely without energy input, unlike unpressurized pneumatic jaws.
In high-temperature or food-handling zones up to 60°C, electric operation avoids pneumatic condensation and contamination concerns.
For rapid setup on flexible production lines, removable centering sleeves and multi-sided mounting speed changeovers versus pneumatic porting and bracket rework.
