What is the gripping force on the ZIMMER GROUP GEP2010IO-00-B?

The GEP2010IO-00-B delivers 200 N of gripping force and can hold workpieces up to 1.3 kg. This compact electric gripper is designed for precise handling of small parts in automated assembly and manufacturing.

What is a parallel gripper?

A parallel gripper uses two fingers that move toward each other in a straight line to grip workpieces from opposite sides. The GEP2010IO-00-B is a 2-finger parallel gripper with 10 mm stroke per jaw, ideal for handling small parts with precision in confined spaces.

How does an electric gripper differ from a pneumatic gripper?

Electric grippers like the GEP2010IO-00-B operate without compressed air infrastructure and require minimal maintenance compared to pneumatic alternatives. This model also features integrated self-locking to hold workpieces securely during power loss and integrates via simple digital I/O control.

What is the stroke on this electric gripper?

The GEP2010IO-00-B has a 10 mm stroke per jaw, allowing each finger to open or close 10 mm. This compact stroke is suitable for precise manipulation of small parts in automated pick-and-place and assembly applications.

Can this gripper hold a part if power is lost?

Yes, the GEP2010IO-00-B has an integrated self-locking mechanism that secures workpieces during power loss. This feature provides added safety and reduces the need for constant electrical power consumption.

What temperature can this electric gripper operate in?

The GEP2010IO-00-B operates reliably up to 60 degrees Celsius without requiring compressed air infrastructure. Its lightweight 0.31 kg design also allows it to fit in confined assembly spaces.

ZIMMER GROUP GEP2010IO-00-B Electric Gripper, 10mm Stroke, 200N

Not sure it fits your cell? Book 20 minutes with an engineer who has specified this part before.

Book a call

Ordered the wrong size or interface? Here is exactly how sending it back works.

In Stock800N Grip

ZIMMER GROUP GEP2010IO-00-B Electric Gripper, 10mm Stroke, 200N

Name: ZIMMER GROUP GEP2010IO-00-B Electric Gripper, 10mm Stroke, 200N
Brand: ZIMMER GROUP
SKU: 3041
Price: 1795 USD
Availability: InStock

ZIMMER GROUP GmbH

$1,795.00

Compact 2-finger electric gripper with 10mm stroke per jaw, 200N gripping force, and integrated self-locking mechanism for maintenance-free handling of small parts in space-constrained automated applications. Digital I/O control, no pneumatics required.

ZIMMER GROUP GEP2010IO-00-B electric parallel gripper is a compact 2-finger end effector engineered for precise handling of small parts in automated manufacturing and assembly systems.

Specifications:

Stroke per jaw: 10 mm
Gripping force: 200 N
Workpiece capacity: Up to 1.3 kg
Weight: 0.31 kg
Operating temperature: Up to 60°C

Features:

Maintenance-free electric operation
Integrated self-locking mechanism secures workpieces during power loss
Digital I/O control simplifies integration with PLCs and automation controllers
Compact 0.31 kg design fits confined spaces
Multiple mounting surfaces for flexible fixture configuration

Applications:

Automated manufacturing
Assembly systems
Pick-and-place
Machine tending

Technical Details:

The GEP2010IO-00-B electric gripper utilizes parallel jaw movement with a 10 mm stroke per jaw, suitable for precise and reliable manipulation of workpieces up to 1.3 kg. The compact form factor allows integration in restricted spaces and supports machine cells shifting towards electric actuation.

Compared to pneumatic grippers, this electric gripper eliminates the need for compressed air infrastructure and minimizes maintenance. The integrated self-locking feature offers added safety and reduces constant electrical consumption. Multiple mounting points and removable centering sleeves support versatile setups, while digital I/O simplifies compatibility with existing PLCs and other end effectors in automation environments.

For buyers seeking alternatives or complementary solutions, consider related ZIMMER GROUP end effectors, pneumatic grippers, or compatible automation controllers for expanded functionality.

Weight0.31 kg

Stroke per jaw10 mm

Max Gripping force: 200 N
Recommended workpiece weight: 1.3 kg
Propulsion Method: Electric
Max. ambient temperature: 60 ℃
Model: GEP2010IO-00-B
Payload: 1.3 kg
Stroke: 10 mm
Gripping Force: 200 N
Operating temperature: 60°C
Control: Digital I/O

Handles small parts precisely, maintenance-free electric operation
Holds workpieces securely during power loss with integrated self-locking
Integrates easily into existing automation via simple digital I/O control
Multiple mounting surfaces and removable centering sleeves enable flexible installation
Grips up to 1.3 kg with 200 N force, 10 mm stroke per jaw
Weighs only 0.31 kg, fits confined assembly spaces
Operates reliably up to 60°C without compressed air infrastructure

: The GEP2010IO-00-B delivers 200 N of gripping force and can hold workpieces up to 1.3 kg. This compact electric gripper is designed for precise handling of small parts in automated assembly and manufacturing.
: A parallel gripper uses two fingers that move toward each other in a straight line to grip workpieces from opposite sides. The GEP2010IO-00-B is a 2-finger parallel gripper with 10 mm stroke per jaw, ideal for handling small parts with precision in confined spaces.
: Electric grippers like the GEP2010IO-00-B operate without compressed air infrastructure and require minimal maintenance compared to pneumatic alternatives. This model also features integrated self-locking to hold workpieces securely during power loss and integrates via simple digital I/O control.
: The GEP2010IO-00-B has a 10 mm stroke per jaw, allowing each finger to open or close 10 mm. This compact stroke is suitable for precise manipulation of small parts in automated pick-and-place and assembly applications.
: Yes, the GEP2010IO-00-B has an integrated self-locking mechanism that secures workpieces during power loss. This feature provides added safety and reduces the need for constant electrical power consumption.
: The GEP2010IO-00-B operates reliably up to 60 degrees Celsius without requiring compressed air infrastructure. Its lightweight 0.31 kg design also allows it to fit in confined assembly spaces.

Electric gripper versus pneumatic for small-part precision:

The GEP2010IO-00-B is an electric parallel gripper for handling small parts, contrasted with pneumatic alternatives that require compressed air infrastructure and ongoing maintenance. Choose this electric option when you need maintenance-free operation, no air lines, and secure grip during power loss.

For parts under 1.3 kg on confined assembly cells, the 0.31 kg weight and 10 mm stroke grip precisely without bulky pneumatic plumbing.
On high-speed pick-and-place lines where air leaks waste energy, electric operation with digital I/O control integrates directly into existing PLCs with no compressor downtime.
For workholding safety during power interruptions, the integrated self-locking mechanism holds parts securely without continuous power draw, unlike pneumatic grippers that depend on constant air pressure.
In tight collaborative or confined robotic cells, the compact form and removable centering sleeves mount flexibly where pneumatic lines create routing constraints.
In clean-room or temperature-controlled environments up to 60°C, electric operation eliminates moisture and oil carryover from compressed air systems.
